6K-6.5K Tuggers



Porta Pull Journeyman 6000 lb cable puller

The Journeyman 6000 lb tugger offers a complete and easy wire pulling  solution! Sets up is only a minute and requires just 1 person to operate. Package includes a heavy duty Pipe Threading kit with 1/2 thru 2 inch R-11 Dies that doubles as a 2-Speed removable Power Unit. it also includes a sturdy carry case.

This Journeyman 6000 lb tugger is a true innovative alternative to   the more bulky and expensive competitor 6K cable tuggers.

  Wire Capacity:

  3 x 750 kcmil cables 500 ft with 4-90 degree bends.
  3 x 600 kcmil cables 600 ft with 4-90 degree bends.
  5 x 500 kcmil cables 450 ft with 4-90 degree bends.



    Features:

    * 6000 lbs Pulling Force from any Direction
   * Power drive for pulling or threading pipe
   * 30% more pulling force than competitors
   * 1.8 HP Two Speed Motor and Gearbox
   * Designed for 1 Person Operation
   * Pulling Speed Low No load-10 fpm
   * Pulling Speed High No load-16 fpm
   * Pulling Speed at Load 6,000 lbs-6 fpm
   * Universal Head fits 1 inch thru 4 inch Conduit
   * 3 inch thru 4 inch HD Adapters Included
   * Professional all spur gear drive Pipe Threader kit
   * 1/2 thru 2 inch threading dies in a sturdy carry case
   * Right angle sheave for operator safety
   * Remote foot switch with Force Gauge
   * Extends over 14 feet in length.
   * Full 2-year Warranty Parts and Labor


  The Journeyman 6000 lb Tugger $3995.00









  The Porta Pull Master 6500 lb cable puller:

  the most Versatile Cable Tugger on the market It comes standard with
  a 2-speed Motor and gear box for efficient cable pulling.

   Features:

  * 6500 lbs. Pulling Force from any Direction.
  * Compact, Powder coated tubular steel frame
  * Planetary gear design for smooth Capstan power
  * 30% more pulling force than competitive models.
  * 2 HP Two Speed Motor and Gearbox.
  * Self-Contained Design for 1 Person Operation.
  * Pulling Speed Low No load-10.5 fpm
  * Pulling Speed High No load-30 fpm
  * Pulling Speed at Load 6,000 lbs-7 fpm
  * Universal Head fits 1 thru 4 inch Conduit.
  * Right angle sheave for operator safety.
  * Remote foot switch with Force Gauge included.
  * Extends over 14 feet in length.
  * Milwaukee 13A Super Hole Hawg motor included


  The Master series 6500 lb Tugger $3995.00







  Wire Capacity:

   4 x 750 kcmil cables 500 ft with 3-90 degree bends
  4 x 600 kcmil cables 500 ft with 4-90 degree bends
  4 x 500 kcmil cables 600 ft with 4-90 degree bends
12 x 4/0 cables 500 ft with 3-90 degree bends
